Solenoids/Manual overrides NG4
For explosion-hazard zones Solenoid coil in acc. with directive 2014/34/EU (ATEX) for explosion-hazard zones. The flameproof enclosures (acc. to EN/IEC 60079-1/31) prevents an explosion in the interior from getting outside. The design prevents a surface temperature capable of igniting. The steel housing is AISI 316L Optional with integrated amplifier electronics.
- Solenoid coil MKY45/18x60
- For explosion-hazard zones
- Protection class IP65/66/67
- Surface AISI 316L
- Optional with integrated amplifier electronics
The solenoid coil is suitable for use in all explosion-hazard zones, open cast and also in mines.
This signifies, that the coils are certified for applications in zones with explosion-hazard gas, steam, vapour, air and dust mixtures of the zones 1/21 and 2/22.
Valves for explosion-hazard zones are utilised in:
– the shipping- and offshore industries
– the oil- and gas industries
– the chemical industry
– wood processing
– grain mills
– the mining application
In combination with an armature tube, the function of a switching solenoid or of a proportional solenoid results. Solenoid coils in AC - construction have an integrated rectifier. All cable threaded joints certified for this explosion protection class with a protection class of at least IP65 can be used. The optional amplifier electronics have an analogue interface and can be adjusted by means of push-buttons and 7 segment display or by means of the parameterisation software PASO.
