Solenoids Solenoids
Solenoid

CHARACTERISTICS DC AC Solenoid SIS45V
Static pressure tightness 160 bar (seal diameter of valve Totale stroke (mm) 5,5 5,5 to VDE 0580
max. 26 mm) Working stroke (mm) 2,5 2,5
Coil winding insulation class H Nominal power (W) 30 Plug plate to ISO 4400 / DIN 43650
Connection / Power supply Over device plug connection to (VA) 35 Protection class IP65
ISO 4400 / DIN 43650, (2P+E), Armature weight (kg) 0,055 0,055
other connections on request. Solenoid weight (kg) 0,76 0,76
Protection class EN 60 529 IP65 Voltage range (VDC) 10-250
Relative duty factor 100 % (VAC) 40-250∗
Reference temperature 50 °C DESCRIPTION fuNCTION APPLICATION
Seal Viton, other on request The SIS45V is a switching solenoid. Its design When the solenoid is energised with the speci- Essential for hydraulic directional and poppet
Fluid Mineral oil, other fluid on request corresponds to VDE standard 0580. The steel fied nominal voltage, the armature moves from valves. Because of the risk of overheating, the
Switching cycles 15 000/h ∗ For AC voltages below 40 VAC DC solenoids plus rectifier plugs housing has a zinc coated finish as standard. the starting position of its stroke (s = 5,5 mm) to solenoid must never be used separately. The
Mounting screws 4 x M5 (Quality 8.8) are available. Static pressure tightness is 350 bars. All the end position (s = 0 mm). The switching time lenght of the fixing screws depends on the base
Housing Zinc coated steel housing, other 21 VDC to 24 VAC o-rings are Viton. The solenoids are fixed to is essentially dependent on the application. material of the body. An o-ring is used for the
surface treatments on request. 32 VDC to 36 VAC the valve with four screws. Depending on the The power stroke characteristics are designed valve seal. Information on screws and o-rings
intended use, the solenoid can be supplied to suit the requirements of hydraulic valves. will be found in the data sheets relating to the
with a plug screw, or with integrated manual AC versions include an electronic rectifier valves concerned. Before changing the plug
12VDC 24VDC 115VAC 230VAC override. The connector plate corresponds to integrated into the connector plate. In this way screw or the screw with integrated manual
Nominal resistance (Ω) 5 21,8 445 1'400 ISO 4400 and DIN 43650. maximum performance is assured. override, care must be taken to ensure that the
Number of windings (-) 770 1’560 7’000 13’000 solenoid is not under pressure. Risk of injury!
Inductivity (mH) 16 72 - - The maximum operating pressure is deter-
minded by the valve actually used.
TyPE CODE
SI S 45 V - - #
Solenoid
Industrial execution
PERFORMANCE ACCESSOIRES Super
F = f (s) Force-stroke characteristics Plug HB0 ∗ Article No. 239.2033 Square 45 mm housing
Plug with integrated manual override HB6 ∗ Article No. 253.8001 Solenoid completly potted
F [N] ∗ acc. data sheet 1.1-300 Nominal voltage U 12 VDC G12
160 K0063 N 24 VDC G24
Special manual override see data sheet 1.1-310 115 VAC R115 ∗
140 230 VAC R230 ∗
Plug grey Article No. 219.2001 AC= 50 to 60 Hz
Plug black Article No. 219.2002 ∗ Rectifier integrated in the plug plate
120 Other nominal voltages and nominal power on request
Rectifier plug grey Article No. 219.2105
100 Rectifier plug black Article No. 219.2106 with mounted screw plug (data sheet 1.1-300) HB0
with mounted manual override (data sheet 1.1-300) HB6
with mounted special manual override (data sheet 1.1-310) H...
80
Design-Index (Subject to change)
60
1 DIMENSIONS
40
2
20 11,2
6
0
0 1 2 3 4 5 s [mm]
8 x0,75 84 6,5

M 4,9
26 55,5 9,8 13,6
5,5
1: U = 100 % U Reference temperature = 20 °C (30W) (∅2)
N
2: U = 90 % U Reference temperature = 50 °C
N
Solenoid in operating temperature (19W) 5,5
The values refer to U = 24 VDC. 54,5 2,2 35,36
N
With other nominal voltages deviations can occur.
For curve 2 the solenoids has been mounted on a body  46 x 64. 64,2 45 10*
74
Technical explanation see data sheet 1.1-400 * Solenoid energised (s= 0 mm)

Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no. Wandfluh AG Tel. +41 33 672 72 72 E-mail: sales@wandfluh.com Illustrations not obligatory Data sheet no.
Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.1-120E 2/2 Postfach Fax +41 33 672 72 12 Internet: www.wandfluh.com Data subject to change 1.1-125E 1/2
CH-3714 Frutigen Edition 06 20 CH-3714 Frutigen Edition 06 20
