Solenoids                                                                                                                    Solenoids
                                                                                                    Solenoid

       CHARACTERISTICS                                                                  DC         AC                              Solenoid SIN45V
       Static pressure tightness   350 bar (seal diameter of valve    Totale stroke  (mm)   4      4                               to VDE 0580
                            max. 19 mm)                     Working stroke        (mm)   1,7       1,7                             Plug plate to ISO 4400 / DIN 43650
                            With seal diameter of valve = 32 mm:  Nominal power       (W)   22
                            Static pressure tightness = 120 bar                (VA)                25                              Protection class IP65
       Coil winding insulation class  H (180 °C)            Armature weight    (kg)     0,024      0,024
       Connection / Power supply   Over device plug connection    Solenoid weight       (kg)   0,45  0,45
                            to ISO 4400 / DIN 43650, (2P+E),    Voltage range       (VDC)   10-250
                            other connections on request.                       (VAC)              24-250
       Protection class to EN 60 529  IP65                                                                                         DESCRIPTION                        FUNCTION                           APPLICATION
       Relative duty factor   100 %                                                                                                The SIN45V is a switching solenoid. Its design   When the solenoid is energised with the speci-  Essential for hydraulic directional and poppet
       Reference temperature   50 °C                                                                                               corresponds to VDE standard 0580. The steel   fied nominal voltage, the armature moves from   valves. Because of the risk of overheating, the
       Seal                 Viton, other on request                                                                                housing has a zinc coated finish as standard.   the starting position of its stroke (s = 5,5 mm) to   solenoid must never be used separately. The
       Fluid                Mineral oil, other fluid on request                                                                    Static pressure tightness is 160 bars. All o-rings   the end position (s = 0 mm). The switching time   lenght of the fixing screws depends on the base
       Switching cycles     15 000/h                                            12VDC   24VDC   115VAC  230VAC                     are Viton. The solenoids are fixed to the valve   is essentially dependent on the application.   material of the body. An o-ring is used for the
       Mounting screws      4 x M4 (Quality 8.8)            Nominal resistance (Ω)   7,2   25   420   1'500                        with four screws. Depending on the intended   The power-stroke characteristics are designed   valve seal. Information on screws and o-rings
       Housing              Zinc coated steel housing,      Number of windings (-)   800   1’550   5’930   11’400                  use, the solenoid can be supplied with a plug   to suit the requirements of hydraulic valves.   will be found in the data sheets relating to the
                            other surface treatments on request.  Inductivity (mH)   14   60   -      -                            screw, or with integrated manual override. The   AC  versions  include  an  electronic  rectifier   valves concerned. Before changing the plug
                                                                                                                                   connector plate corresponds to ISO 4400 and   integrated into the connector plate. In this way   screw or the screw with integrated manual
                                                                                                                                   DIN 43650.                         maximum performance is assured.    override, care must be taken to ensure that the
                                                                                                                                                                                                         solenoid is not under pressure. Risk of injury!
                                                                                                                                                                                                         The maximum operating pressure is determin-
                                                                                                                                                                                                         ded by the valve actually used.

                                                                                                                                                                      TYPE CODE
                                                                                                                                                                                                                 SI  N  45  V  -   -   #
                                                                                                                                                                      Solenoid
                                                                                                                                                                      Industrial execution
       PERFORMANCE                                          ACCESSOIRES                                                                                               Normal
       F = f (s)   Force-stroke characteristics                                                                                                                       Square 45 mm housing
                                                            Plug HB0                         ∗ Article No. 239.2033
                                                            Plug with integrated manual override HB4,5   ∗ Article No. 253.8000                                       Solenoid completly potted
           F [N]                                                                           ∗ acc. data sheet 1.1-300
                                                                                                                                                                                   N
        130  K0115                                                                                                                                                    Nominal voltage U         12 VDC     G12

                                                                                                                                                                                                           G24
                                                                                                                                                                                                24 VDC
        120                                                 Special manual override         see data sheet 1.1-310                                                                              115 VAC    R115  ∗
                                                                                                                                                                                                230 VAC    R230  ∗
        110                                                 Plug grey                         Article No. 219.2001                                                    AC= 50 to 60 Hz
                                                            Plug black                        Article No. 219.2002                                                    ∗ Rectifier integrated in the plug plate
        100
                                                                                                                                                                      Other nominal voltages and nominal power on request
         90
         80                                                                                                                                                           with mounted screw plug (data sheet 1.1-300)   HB0
                                                                                                                                                                      with mounted manual override (data sheet 1.1-300)   HB6
         70                                                                                                                                                           with mounted special manual override (data sheet 1.1-310)   H...
         60                                                                                                                                                           Design-Index (Subject to change)
         50
                                1                                                                                                  DIMENSIONS
         40
         30
                         2                                                                                                                                                                                          11,2
         20
                                                                                                                                                                                                                       6
         10
          0                                                                                                                          x0,75
            0  0.5  1  1.5  2  2.5  3  3.5  4  s [mm]                                                                                8                              4,9     84                                                     6,5
                                                                                                                                     M
                                                                                                                                                                       26  55,5                                                       9,8  13,6
                                                                                                                                                                                                       5,5
       1: U = 100 % U N   Reference temperature = 20 °C (22W)
       2: U = 90 % U      Reference temperature = 50 °C
                N
                        Solenoid in operating temperature (15W)
       The values refer to U  = 24VDC.                                                                                                               54,5        2,2                       35,36
                      N
       With other nominal voltages deviations can occur.
       For curve 2 the solenoid has been mounted on a body  38 x 54.                                                                               64,2                                    45                           10*
                                                                                                                                                   74
                                                                                                                                   * Solenoid energised (s= 0 mm)
                                                            Technical explanation see data sheet 1.1-400

       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-110E 2/2              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-120E 1/2
       CH-3714 Frutigen                                                                            Edition 17 01                   CH-3714 Frutigen                                                                             Edition 06 20
