Page 28 - Softbound_Edition_19_en

Solenoid
Solenoids Solenoids

CHARACtERIStICS 12VDC 24VDC Solenoid SIN35V
Static pressure tightness 350 bar (seal diameter of valve Totale stroke (mm) 2,5 2,5 to VDE 0580
max. 15 mm) Working stroke (mm) 1 1 Plug plate to ISO 4400 / DIN 43650
Coil winding insulation class H Rated force (N) 29 29
Connection / Power supply Over device plug connection to Hysteresis of rated force (%) 5,5 5,5 Protection class IP65
ISO 4400 / DIN 43650, (2P+E), Hysteresis of rated current (%) 5,5 5,5
other connections on request Nom. linearity deviation (%) 4,5 4,5
Protection class EN 60 529 IP65 Rated resistance (Ω) 7,2 31
Relative duty factor 100 % Rated current (A) 1,08 0,54
Reference temperature 50 °C Limiting current (A) 1,08 0,54 DESCRIPtION fuNCtION APPLICAtION
Seal Viton, other on request Linearity current (A) 0,2 0,1 The SIN35V is a switching solenoid. Its design When the solenoid is energised with the speci- Essential for hydraulic directional and poppet
Fluid Mineral oil, other fluid on request Actuation current (A) 0,02 0,01 corresponds to VDE standard 0580. The steel fied nominal voltage, the armature moves from valves. Because of the risk of overheating, the
Mounting screws 4 x M3 (Quality 8.8) Nominal wattage (W) 8,1 8,8 housing is zinc coated as a standard. Static the starting position of its stroke (s = 3,2 mm) solenoid must never be used separately. The
Housing Zinc coated steel housing, other Performance limit (W) 13 13 pressure tightness is 160 bars. All o-rings are to the end position (s = 0 mm). The switching lenght of the fixing screws depends on the base
surface treatments on request Number of windings (-) 645 1'310 Viton. The solenoids are fixed to the valve time is essentially dependent on the application. material of the body. An o-ring is used for the
Inductivity (mH) 12 45 with four screws. Depending on the intended The power stroke characteristics are designed valve seal. Information on screws and o-rings
Armature weight (kg) 0,014 0,014 use, the solenoid can be supplied with a plug to suit the requirements of hydraulic valves. AC will be found in the data sheets relating to the
Solenoid weight (kg) 0,21 0,21 screw, or with integrated manual override. The versions include an electronic rectifier integrated valves concerned. Before changing the plug
connector plate corresponds to ISO 4400 and into the connector plate. In this way maximum screw or the screw with integrated manual
DIN 43650. performance is assured. override, care must be taken to ensure that the
solenoid is not under pressure. Risk of injury!
The maximum operating pressure is determin-
ded by the valve actually used.
tyPE CODE
PERfORMANCE
F = f (s) Force-stroke characteristics F = f (I) Force-current characteristics SI N 35 V - - #
Solenoid
F [N] F [N] Industrial execution
35 K0110 1.2 l G 35 K0111 Normal
Square 35 mm housing
30 1.0 l G 30 Solenoid completly potted
Nominal voltage U 12 VDC G12
N
24 VDC G24
25
25 115 VAC R115 ∗
1.8 l G 230 VAC R230 ∗
AC= 50 to 60 Hz
20 20 ∗ Rectifier integrated in the plug plate
Other nominal voltages and nominal power on request
0.6 l G 15
15 with mounted screw plug (data sheet 1.1-300) HB0
with mounted manual override (data sheet 1.1-300) HB4,5
10 with mounted special manual override (data sheet 1.1-310) H...
10 0.4 l G
Design-Index (Subject to change)
5
5
0.2 l G
0 DImENSIONS
0
0 0.5 1 1.5 2 2.5 s [mm] 0 20 40 60 80 100 I [%] 6,25
G
 1,25
= Working stoke

ACCESSOIRES 8 x0,75
Plug HB0 Article No. 239.2033 2,9 74 4
data sheet 1.1-300 M
Plug with integrated manual override HB4,5 Article No. 253.8000 32 45,5 8
data sheet 1.1-300 4,5 12,5

Plug grey Article No. 219.2001
Plug black Article No. 219.2002
53 2,2
59,2 28
70 35 9,9*
Technical explanation see data sheet 1.1-410 * Solenoid energised (s= 0 mm)
