Solenoid
                                                                                                   Solenoids                                                                                                                    Solenoids

       CHARACTERISTICS                                                                  DC         AC                              Solenoid SIS60V
       Static pressure tightness   160 bar (seal diameter of valve    Totale stroke  (mm)   8,5    8,5                             to VDE 0580
                            max. 32 mm)                     Working stroke       (mm)   4          4                               Plug plate to ISO 4400 / DIN 43650
       Coil winding insulation class  H                     Nominal power       (W)     40
       Connection / Power supply   Over device plug connection to              (VA)                46                              Protection class IP65
                            ISO 4400 / DIN 43650, (2P+E),    Armature weight   (kg)     0,124      0,124
                            other connections on request    Solenoid weight       (kg)   1,90      1,90
       Protection class EN 60 529   IP65                    Voltage range       (VDC)   10-250
       Relative duty factor   100 %                                            (VAC)               50-250∗
       Reference temperature   50 °C                                                                                               DESCRIPTION                        FUNCTION                           APPLICATION
       Seal                 Viton, other on request                                                                                The SIS60V is a switching solenoid. Its   When the solenoid is energised with the speci-  Essential for hydraulic directional and poppet
       Fluid                Mineral oil, other fluid on request  ∗  For AC voltages below 50 VAC  DC solenoids plus rectifier plugs     design corresponds to VDE standard 0580.   fied nominal voltage, the armature moves from   valves. Because of the risk of overheating, the
       Switching cycles     15 000/h                           are available.                                                      Static pressure-tightness is 350 bars. All    the starting position of its stroke (s = 8,5 mm) to   solenoid must never be used separately. The
       Mounting screws      4 x M6 (Quality 8.8)               21 VDC  to  24 VAC                                                  o-rings are Viton. The solenoids are fixed to   the end position (s = 0 mm). The switching time   lenght of the fixing screws depends on the base
       Housing              Zinc coated steel housing,         32 VDC  to  36 VAC                                                  the valve with four screws. Depending on the   is essentially dependent on the application.   material of the body. An o-ring is used for the
                            other surface treatments on request.     36 VDC  to  42 VAC                                            intended use, the solenoid can be supplied   The power-stroke characteristics are designed   valve seal. Information on screws and o-rings
                                                               42 VDC  to  48 VAC                                                  with a plug screw, or with integrated manual   to suit the requirements of hydraulic valves.   will be found in the data sheets relating to the
                                                                                                                                   override. The connector plate corresponds to   AC versions include an electronic rectifier   valves concerned. Before changing the plug
                                                                                                                                   ISO 4400 and DIN 43650.            integrated into the connector plate. In this way   screw or the screw with integrated manual
                                                                                12VDC   24VDC   115VAC  230VAC                                                        maximum performance is assured.    override, care must be taken to ensure that the
                                                            Nominal resistance (Ω)   4   16,5   260   920                                                                                                solenoid is not under pressure. Risk of injury!
                                                            Number of windings (-)   780   1’580   5’710   11’200                                                                                        The  maximum  operating  pressure  is  deter-
                                                            Inductivity (mH)    19      75     -      -                                                                                                  minded by the valve actually used.

                                                                                                                                                                      TYPE CODE
                                                                                                                                                                                                                      SI  S  60  V  -   #
                                                                                                                                                                      Solenoid
       PERfORMANCE                                          ACCESSOIRES
                                                                                                                                                                      Industrial execution
       F = f (s)   Force-stroke characteristics
                                                            Plug HB0                         ∗ Article No. 239.2033                                                   Super
                                                            Plug with integrated manual override HB8,5   ∗ Article No. 253.8002                                       Square 60 mm housing
          F [N]                                                                            ∗ acc. data sheet 1.1-300
        350  K0204                                                                                                                                                    Solenoid completly potted
                                                            Special manual override         see data sheet 1.1-310                                                    Nominal voltage U         12 VDC     G12
                                                                                                                                                                                   N
        300                                                 Plug grey                         Article No. 219.2001                                                                              24 VDC     G24
                                                                                                                                                                                                115 VAC
                                                                                                                                                                                                           R115  ∗
                                                            Plug black                        Article No. 219.2002                                                                              230 VAC    R230  ∗
        250                                                                                                                                                           AC= 50 to 60 Hz
                                                            Rectifier plug grey               Article No. 219.2105                                                    ∗ Rectifier integrated in the plug plate
                                                            Rectifier plug black              Article No. 219.2106                                                    Other nominal voltages and nominal power on request
        200
                                                                                                                                                                      Design-Index (Subject to change)
        150


        100

         50                     1                                                                                                  DIMENSIONS

                        2
          0                                                                                                                                                                                                              11,5
                                                                                                                                       8 x0,75                                                                                        6,8
           0     2     4    6     8    10  s [mm]
                                                                                                                                       M                              4,9     99
       1: U = 100 % U    Reference temperature = 20 °C (40W)                                                                                                               70,5
                 N
       2: U = 90 % U    Reference temperature = 50 °C                                                                                20                                 32                                                              15,5
                N
                     Solenoid in operating temperature (25W)                                                                                                                                           6,5
       The values refer to U  = 24 VDC.                                                                                                                                                                         (∅2)
                      N
       With other nominal voltages deviations can occur.
       For curve 2 the solenoid has been mounted on a body  62 x 93.                                                                                                                                           8
                                                                                                                                                0,3               2,2                      48,08                             10*
                                                                                                                                                     81,5                                   60
                                                                                                                                                     85

                                                                                                                                   * Solenoid energised (s= 0 mm)

                                                            Technical explanation see data sheet 1.1-400

       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-145E 2/2              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-150E 1/2
       CH-3714 Frutigen                                                                            Edition 05 01                   CH-3714 Frutigen                                                                             Edition 18 25
