Brake Systems

08.06.2018

Sensitive hydraulic valves for all types of brake systems

The new Wandfluh hydraulique valves are direct operated valves in screw-in cartridge construction. These are available in two different sizes and cavities. The smaller models of the MDPPM16 and MGPPM16 series have been designed for a maximum flow of 6 l/min. The cartridge body is provided with a M16x1.5 thread. With the larger models in the MPPPU10 series, a maximum flow of 20 l/min can be achieved. The cartridge body has a 7/8“-14 UNF cavity. With the larger models in the MPPPU10 series, a maximum flow of 20 l/min can be achieved. The cartridge body has a 7/8“-14 UNF cavity.

Through these small dimensions, the requirements of many users for a compact, space-saving design have been met. Hydraulic brakes for low-floor vehicles such as trams or local trains, where, as is generally known, only little installation space is available, are typical examples.

Further details can be found in the Brochure <link http: www.wandfluh.ch fileadmin user_upload wandfluh downloads kommunication brochures wag english brakesystems external-link-new-window internal link in current>Brake Systems.
(<link http: www.wandfluh.ch fileadmin user_upload wandfluh downloads kommunication brochures wac_brochures chinese brakesystems mobile index.html _blank external-link-new-window external link in new>制动系统 Brake Systems)
